Higgs®-9
Featuring industry leading data integrity & reliability, Higgs™ 9 delivers cutting edge read / write sensitivty and flexible memory capacity designed to fit with today’s demanding applications and the evolving IoT information base.
Features Benefits
| FEATURE | BENEFIT | DESCRIPTION |
|---|---|---|
|
Sentinel™ Memory  |
Detects and fixes single bit errors and flags dual bit errors.
|
Safeguarded data and immunity to typical sources of single bit errors (chip damage, low power etc.)
|
|
Read sensitivity
|
Up to -20 dBm
|
Allows smaller tags to be designed or larger read & write distances to be realized. Robust memory retention (twice that of competition) |
|
Write sensitivity
|
Up to -18 dBm
|
|
|
Best in class memory reliability
|
200,000 write cycles
|
|
|
96-bit expandable EPC
|
Supports EPC size up to 496b for flexibility
|
Additional 400 bits allows storing of larger identifying information
|
|
688 bit user memory
|
User memory for storage of additional application data.
|
For applications requiring data beyond EPC (asset data, service history, usage info etc.)
|
|
48b UTID with lower 38b unique serial for SGTIN generation
|
48b UTID. Lower 38b are duplicated in the EPC for SGTIN generation.
|
For retail and general serialzation
|
|
Larger “pads” for improved antenna connectivity
|
More contact area for antenna connectivity
|
Increased and more consistent yield inlay to inlay
|
These products are covered by one or more of the following U.S. patents: 7967204, 7931063, 7868766, 7737825, 7716208, 7716160, 7688206, 7671720, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7551141, 7542301, 7542008, 7522055, 7500610, 7489248, 7453705, 7452748, 7425467, 7417306, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157, 6942155, 6933848. Other patents pending.
